Frequency range

1080-1100 MHz

Return Loss

≥18 dB

Insertion loss

≤0.5 dB

Rejection

≥40dB@DC-1040MHz

≥40dB@1140-3000MHz

Power Handling CW

Power Handling Peak

20W at 1020-1040MHz(blocking);and 1W at 1090MHz(pass)

4000W at 1020-1040MHz(blocking);and 1W at 1090MHz(pass)

Temperature Range

-30-+70℃

Impedance

50 Ω
