Frequency range

12.6-16.5GHz

Return loss

≥15dB (type18dB)

Insertion loss

≤2.0dB

Ripple in band

≤1.5dB

Rejection

≥80dB @ DC-11.1GHz

≥25dB @ 11.1-12.4GHz

≥30dB @ 16.85-17.1GHz

≥80dB @ 17.1-25GHz

Temperature range

-30°C to +70°C

Power

5W

Impedance

50Ω
