Frequency range F0

7450 MHz (type 7045.8MHz)

Bandwidth

4841MHz

Return Loss

≥9.5dB

Insertion loss

≤1.7 dB (type ≤1.49 dB)

Rejection

≥157dB@920MHz

(type ≤175.15dB)

≥41dB@10800MHz

(type ≤46.53dB)

Operating temperature range

-40 to +70℃

Max power

30dBm

Impedance

50 Ω
