Frequency range

758-803MHz

869-894MHz

1930-1990MHz

2110-2200MHz

2620-2690MHz

Center frequency

780.5MHz

881.5MHz

1960MHz

2155MHz

2655MHz

Return loss

≥18dB

≥18dB

≥18dB

≥18dB

≥18dB

Center frequency insertion loss(Normal temp)

≤0.6dB

≤0.6dB

≤0.6dB

≤0.5dB

≤0.6dB

Center frequency insertion loss(Full temp)

≤0.65dB

≤0.65dB

≤0.65dB

≤0.5dB

≤0.65dB

Insertion loss (Normal temp)

≤1.3dB

≤1.2dB

≤1.3dB

≤1.2dB

≤1.2dB

Insertion loss (Full temp)

≤1.3dB

≤1.2dB

≤1.6dB

≤1.2dB

≤1.2dB

Ripple (Normal temp)

≤0.9dB

≤0.7dB

≤0.7dB

≤0.7dB

≤0.7dB

Ripple (Full temp)

≤1.0dB

≤0.7dB

≤1.3dB

≤0.7dB

≤0.8dB

Rejection

≥40dB@DC-700MHz

≥75dB@703-748MHz

≥70dB@824-849MHz

≥70dB@1850-1910MHz

≥70dB@1710-1770MHz

≥70dB@2500-2570MHz

≥40dB@2750-3700MHz

≥40dB@DC-700MH

≥70dB@703-748MHz

≥75dB@ 824-849MHz

≥70dB@1850-1910MHz

≥70dB@1710-1770MHz

≥70dB@2500-2570MHz

≥40dB@2750-3700MHz

≥40dB@DC-700MHz

≥70dB@703-748MHz

≥70dB@824-849MHz

≥75dB@1850-1910MHz

≥75dB@1710-1770MHz

≥70dB@2500-2570MHz

≥40dB@2750-3700MHz

≥40dB@DC-700MHz

≥70dB@703-748MHz

≥70dB@824-849MHz

≥75dB@1850-1910MHz

≥75dB@1710-1770MHz

≥70dB@2500-2570MHz

≥40dB@2750-3700MHz

≥40dB@DC-700MHz

≥70dB@703-748MHz

≥70dB@824-849MHz

≥70dB@1850-1910MHz

≥70dB@1710-1770MHz

≥75dB@2500-257 MHz

≥40dB@2750-3700MHz

Input power

≤60W Average handling power at every input port

Output power

≤300W Average handling power at COM port

Impedance

50 Ω

Temperature range

-40°C to +85°C
