Frequency range

791-821 MHz

925-960 MHz

1805-1880 MHz

2110-2170 MHz

2550-2690 MHz

Return loss

≥17 dB

≥17 dB

≥17 dB

≥17 dB

≥17 dB

Insertion loss

≤0.75 dB

≤0.75 dB

≤0.5 dB

≤0.5 dB

≤0.5 dB

Rejection

≥40dB@832-862MHz

≥40dB@880-915MHz

≥40dB@1710-1785MHz

≥40dB@1920-1980MHz

≥40dB@2500-2570MHz

≥40dB@832-862MHz

≥40dB@880-915MHz

≥40dB@1710-1785MHz

≥40dB@1920-1980MHz

≥40dB@2500-2570MHz

≥40dB@832-862MHz

≥40dB@880-915MHz

≥40dB@1710-1785MHz

≥40dB@1920-1980MHz

≥40dB@2500-2570MHz

≥40dB@832-862MHz

≥40dB@880-915MHz

≥40dB@1710-1785MHz

≥40dB@1920-1980MHz

≥40dB@2500-2570MHz

≥40dB@832-862MHz

≥40dB@880-915MHz

≥40dB@1710-1785MHz

≥40dB@1920-1980MHz

≥40dB@2400-2450MHz

power

250W Average Handling Power at Common Port

Temperature

-40~+85℃

Impedance

50 Ω
