700

850(B5)

900

1800

2100

758-803 MHz

869-880 MHz

925-960 MHz

1805-1880 MHz

2110-2170 MHz

≥18 dB

≥18 dB

≥18 dB

≥18 dB

≥18 dB

≤1.5 dB

≤1.5 dB

≤1.5 dB

≤1.5 dB

≤1.0 dB

≥75 dB

≥75 dB

≥75 dB

≥75 dB

≥60 dB

703-748 MHz & 824-835 MHz & 880-915 MHz & 1710-1785 MHz & 1920-1980 MHz

Note: For band 850, the stop band int the 900 band is not applied.

60dB±8.0dB

+48dBm(60Watt) @ each input      +55dBm(300Watt) @ output

+53dBm(200Watt) @ each input      +60dBm(1000Watt) @ output

50 Ω

850(B5)

900

700 & 1800 & 2100

824-835 MHz

880-915 MHz

703-748 MHz

1710-1785 MHz

1920-1980 MHz

≥18 dB

≥18 dB

≥18 dB

≥18 dB

≥18 dB

≤1.5 dB

≤1.5 dB

≤1.5 dB

≤1.5 dB

≤1.0 dB

≥70 dB @ 758-803&869-880&1805-1880&2110-2170&2300-2400

≥70 dB @ 758-803&925-960&1805-1880&2110-2170&2300-2400

≥70 dB @ 758-803&869-880&925-960&2110-2170&2300-2400

≥65 dB @ 1805-1880

+30dBm

50 Ω
